High sensitivity: 200 mW pick-up power
100 mW pick-up power types available
Latching types available
High switching capacity: 60 W, 125 V A
High breakdown voltage: 1,500 V FCC surge between open contacts
1,000 V AC between open contacts
DIP-1C type can be used with 14 pin IC socket
2C type can be used with 16 pin IC socket,
4C type can be used with 2 sets of 14 pin IC sockets
Gold-cap silver palladium types available for 2 Form C type
Bifurcated contacts are standard

Features

The features of DS2E-S-DC5V can be summarized as (1)High sensitivity: 200 mW pick-up power; (2)100 mW pick-up power types available; (3)Latching types available; (4)High switching capacity: 60 W, 125 V A; (5)High breakdown voltage: 1,500 V FCC surge between open contacts; (6)1,000 V AC between open contacts; (7)DIP-1C type can be used with 14 pin IC socket; (8)2C type can be used with 16 pin IC socket,; (9)4C type can be used with 2 sets of 14 pin IC sockets; (10)Gold-cap silver palladium types available for 2 Form C type; (11)Bifurcated contacts are standard
