Product Summary

The SIM700 is a complete Quad-Band GSM/GPRS/EDGE solution in a compact plug-in module. Featuring an industry-standard interface, it delivers GSM/GPRS/EDGE 850/900/1800/1900MHz performance for Data, Voice, SMS, and Fax in a small form factor and with low power consumption. The leading features of the Module make it ideal for virtually unlimited applications, such as PC card, USB modem, handheld devices, M2M applications and much more.

Parametrics

SIM700 absolute maximum ratings: (1)Quad-Band GSM/GPRS/EDGE 850/900/1800/1900MHz; (2)Mobile station class B; (3)Multi-slot class 12 ; (4)Uplink or downlink max throughput: 236.8kbps ; (5)Low power consumption ; (6)Output power: GMSK: Class 4 (2W)@GSM850/EGSM900; Class 1 (1W)@DCS1800/PCS1900; 8PSK: Class E2 (0.5W)@GSM850/EGSM900; Class E2 (0.4W)@DCS1800/PCS1900 ; (7)Control via AT commands (GSM 07.07 ,07.05 and SIMCOM enhanced AT Commands) ; (8)Supply voltage range: 3.4V-4.5V .

Features

SIM700 features: (1)CSD: up to 14.4kbps, non-transparent; (2)GPRS: max: 85.6kbps; (3)EDGE: DL&UL max: 236.8kbps; (4)Coding scheme: CS1~4, MCS1~9; (5)Support PBCCH; (6)Support USSD.

Diagrams

SIM700 block diagram

SIM765170
SIM765170
Other

Data Sheet
Negotiable
