Product Summary
The SN65LV1224BDBR is a deserializer. It comprises a 10-bit serdes chipset designed to transmit and receive serial data over LVDS differential backplanes at equivalent parallel word rates from 10 MHz to 66 MHz. The SN65LV1224BDBR can be entered into a power-down state when no data transfer is required. Alternatively, a mode is available to place the output pins in the high-impedance state without losing PLL lock. The SN65LV1224BDBR is characterized for operation over ambient air temperature of -40℃ to 85℃.
Parametrics
SN65LV1224BDBR absolute maximum ratings: (1)V CC to GND:-0.3V to 4V; (2)LVTTL input voltage:-0.3V to (V CC + 0.3V); (3)LVTTL output voltage:-0.3V to (V CC + 0.3V); (4)LVDS receiver input voltage:-0.3V to 3.9V; (5)LVDS driver output voltage:-0.3V to 3.9V; (6)Junction temperature:150℃; (7)Storage temperature:-65℃ to 150℃; (8)Lead temperature (soldering, 4 seconds) 260℃; (9)Electrostatic discharge: HBM:up to 6kV, MM:up to 200V.
Features
SN65LV1224BDBR features: (1)100-Mbps to 660-Mbps Serial LVDS Data Payload Bandwidth at 10-MHz to 66-MHz System Clock; (2)Pin-Compatible Superset of DS92LV1224; (3)Chipset (Serializer/Deserializer) Power Consumption <450 mW (Typ) at 66 MHz; (4)Synchronization Mode for Faster Lock; (5)Lock Indicator; (6)No External Components Required for PLL; (7)28-Pin SSOP and Space Saving 5 × 5 mm QFN Packages Available; (8)Industrial Temperature Qualified, TA = -40℃ to 85℃; (9)Programmable Edge Trigger on Clock; (10)Flow-Through Pinout for Easy PCB Layout.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN65LV1224BDB |
Texas Instruments |
LVDS Interface IC 1:10 LVDS Serdes Rcvr 100 - 660Mbps |
Data Sheet |
|
|
||||||||||||
|
SN65LV1224BDBG4 |
Texas Instruments |
LVDS Interface IC 1:10 LVDS Serdes Rcvr 100 - 660Mbps |
Data Sheet |
|
|
||||||||||||
|
SN65LV1224BDBRG4 |
Texas Instruments |
LVDS Interface IC 1:10 LVDS Serdes Rcvr 100 - 660Mbps |
Data Sheet |
|
|
||||||||||||
|
SN65LV1224BDBR |
Texas Instruments |
LVDS Interface IC 1:10 LVDS Serdes Rcvr 100 - 660Mbps |
Data Sheet |
|
|
||||||||||||
